Isolator Module
Tell us how many you need. We send a written price, usually the same working day.
Request a quote- Priced for your order: price and delivery in writing before you pay
- Genuine products: brand and model confirmed before you pay
- Delivery across Bangladesh: every order confirmed by phone before dispatch
- Installation and maintenance: by our team, on request
Key features
- Protects an addressable loop from short circuits
- Isolates only the faulty section
- The rest of the loop keeps working
Specification
| Specification | Details |
|---|---|
| Module Type | Isolator Module |
| System Type | Addressable Fire Alarm System |
| Operating Voltage | 24V DC |
| Loop Current Rating | As per system design |
| Isolation Method | Automatic Electronic Isolation |
| Mounting Type | DIN Rail / Panel Mounted |
| Compatibility | Addressable Fire Alarm Control Panel |
| Operating Environment | Indoor |
Description
An isolator module divides an addressable fire alarm loop into sections. If a cable is damaged and short-circuits, the isolators on either side disconnect only that section, and every other device on the loop keeps working.
Fire codes require isolators so a single fault cannot disable a large part of the system. They are placed between zones and at regular intervals around the loop.
Key features
- Automatic short circuit isolation
- Automatic reconnection once the fault is cleared
- 24 V DC, loop powered
- DIN rail, panel or back-box mounting
- For addressable fire alarm systems
Applications
- Addressable fire alarm loops
- Zone boundaries in large buildings
Before you order
Isolators are made for one panel family, so tell us the addressable panel's brand and model. Count them from your design: usually one between each zone and others at intervals around the loop, so a fault takes out only a small section. Some detector bases and modules have isolators built in, which changes the count.
Installation and care
Fit the isolators in the loop as the design shows, in a back box, panel or on DIN rail. During commissioning, test that a short circuit in one section leaves the rest of the loop working. Our team can install and test the loop on request.
Common questions
What happens without isolators?
A single short circuit can take out every device on the loop, which may be a large part of the building's fire protection.
Does an isolator reset itself?
Yes. Once the fault is cleared, it reconnects the section automatically.
Are isolators used on conventional systems?
No. They are for addressable loops.
Specifications vary by model and manufacturer. We confirm the exact model, rating, price and delivery charge in your written quotation.
What is the price of Isolator Module in Bangladesh?
It depends on the model and how many you need, so we price it for your order. Press "Request a quote", message us on WhatsApp or call +8801670 468794. We send you a written price, usually the same working day.
Delivery and payment
- Delivery
- Anywhere in Bangladesh
- Delivery charge
- Written in your quotation
- Payment
- Terms written in your quotation
- Returns
- 7 days, unused and in the original box
The quotation lists the price, the delivery charge and the delivery date before you pay anything.
